SIMENS PLC automatic Steel cylinder head polishing machine

SIEMENS PLC automatic polishing machine for steel cylinder heads inner & outer surface grinding buffing.

Quantity: - +

Product Description

New Arrival! customized design SIEMENS PLC automatic polishing machine is made up of column and boom,This kind automatic polishing machine is for steel metal cylinder heads,vessel head,tank cap,dish head,spherical cap,dished heads,semi spherical heads interior & exterior surface grinding and buffing.

TCM-D steel polishing machine is suitable for all kinds of standard head polishing,conical head polishing,spherical head surface polishing,dish head polishing,special heads polishing,stainless steel oval head inside and outside surface grinding polishing, pressure vessel head polishing etc.it’s widely used in the fields of pharmaceutical industry,medical industry,food & Beverage industry,water purification,Pressure vessel industry,Cosmetic industry,waste water treatment,Semiconductor industry,Photovoltaic industry etc.

Stainless steel cylinder head automatic polishing machine parameter:

Normal configuration(customers’ requirement acceptable)

Available Polishing workpiece size

(Tank head/dish ends)

Inside & outside diameter

450~5000mm / 6000 mm


Turntable Max.Loading capacity

1 Ton / 2 Ton /5 Ton / 10 Ton for option or custom design 15 Ton,20 Ton.


Polishing Precision

Surface roughness(Ra)

<=0.25μm


Production Efficiency

/

6~12 m2/hour


Total Dimension

Machine Dimension

3500*1600*3080mm


Column Dimension

300x400x8 mm


Beam Dimension

150x200x6 mm


Input total Power

/

12 kw


Power Supply

380V 415V / 50Hz 60HZ / 3p or Customization


Color

Grey/Green/Blue/Red/Yellow Custom design


Machine Weight

/

2250kg


Suitable Polishing Material

Abrasive sanding belts,grinding wheels (flap/cloth/ emery/Nylon wheel etc)


 SIMENS PLC automatic control Steel cylinder head polishing machine  (5).jpg
